Technical parameter
|
Item |
P2 |
P2.5 |
P3 |
P4 |
P5 |
|
Pixel Pitch |
2mm |
2.5mm |
3mm |
4mm |
5mm |
|
Modules size |
320x160mm |
320x160mm |
240x120mm |
256x128mm |
320x160mm |
|
Pixel Density |
250000 dots/sqm |
160000 dots/sqm |
111111 dots/sqm |
62500dots/sqm |
40000dots/sqm |
|
Scan mode |
1/40 Scan |
1/32 Scan |
1/32 Scan |
1/16 Scan |
1/16 Scan |
|
Best Viewing Distance |
2-50m |
2-50m |
3-50m |
4-50m |
5-50m |
|
Best Viewing Angle |
Horizontal: 120° Vertical: 120° |
Horizontal: 120° Vertical: 120° |
Horizontal: 120° Vertical: 120° |
Horizontal: 120° Vertical: 120° |
Horizontal: 120° Vertical: 120° |
|
Avergage Power Consumption |
300W/sqm |
300W/sqm |
300W/sqm |
300W/sqm |
300W/sqm |
|
Working Temperature |
0°C~+50°C |
0°C~+50°C |
0°C~+50°C |
0°C~+50°C |
0°C~+50°C |
|
Refresh Rate |
3840Hz |
3840Hz |
1920Hz |
1920Hz |
1920Hz |
|
Control System |
Synchronous control system |
Synchronous control system |
Synchronous control system |
Synchronous control system |
Synchronous control system |
|
Life Span |
100.000 Hours |
100.000 Hours |
100,000 Hours |
100,000 Hours |
100,000 Hours |
