P1.25 GOB LED Display Screen

1.With the sureface glued on
2.broad point of vision. Visibility of 170 degrees
3.Full-color LED screen panel 1R1G1B
4.Exceptionally stable driver integrated circuits for improved color consistency and vivid visuals
5.Designed using the newest GOB encapsulation, delivering great full color presence.
6.Bright colors are produced with a high contrast ratio of 5000:1.
7.A high refresh rate of more than 1920 Hz to 3840 Hz enables high-definition visual performance without flicker.
8.Compatible with common control systems Novastar, Linsn, Colorlight, Huidu, etc
9.Support a variety of display formats, including documents, images, videos, and text.
10.The range of pixel pitch is P1.25, P2, P2.5, P3, P3.076, P3.91, P4.81, P4, and so on.

Send Inquiry

Description

Technical Parameters

1001

Features

1. High pixels, delicate and realistic picture quality, and pure and thick colors.

2. The flatness is good, the picture is uniform and pleasing to the eye.

3. High grayscale, high refresh, and realistic studio video effects.

4. Safety performance structure, reinforced design is not easy to deform.

5. Large-viewing-angle imaging display technology enables viewing at a wide range of angles without color cast.

6. It can be designed and maintained on the front and back, which is light, fast and easy to maintain.

Application

1.Meeting rooms

Installing a small-pitchP1.25 GOB LED Display Screen panel in a conference room is a great idea because it can clearly display a wide range of text, images, and videos while preserving true color.

2.Numerous exposition halls will select an P1.25 GOB LED Display Screen for their display because it meets their requirements, has a high resolution display screen, a huge and vibrant picture area, and can more clearly portray the contents of the exhibition hall.

3.Retail center

P1.25 GOB LED Display Screen should be used to disseminate activity information from certain stores or show advertising content from certain companies in order to reach a large consumer base and provide pertinent information to them quickly. To draw in more viewers and spread the advertising content to a larger audience, varied display techniques should also be used.

Hot Tags: p1.25 gob LED display screen, China p1.25 gob LED display screen manufacturers, suppliers, factory, led video wall rental, p3 91 led screen, led screen for wall, P2 LED Screen, digital sign board for shop, outdoor electronic signs

Model	GOB led module
Color	RGB
LED encapsulation	SMD2121
Pixel pitch	1.25mm	2mm	2.5mm	3mm	4mm
Scan mode	1/52S	1/40S	1/32S	1/32S	1/16S
Module resolution (W × H)	256*128	160*80	128*64	64*64	64*32
Module size(W × H)	320*160mm	320*160mm	320*160mm	192*192mm	256*128mm
Pixel density (dots/㎡)	640000	250000	160000	160000	62500
Brightness	200cd~600cd/ m², adjustable	≥500cd/ m², adjustable	≥700cd/ m², adjustable	≥700cd/ m², adjustable	≥850cd/ m², adjustable
Current	4.2A±0.1A	2.8A±0.1A	3.6A±0.1A	3.2A±0.1A	3A±0.1A
Input voltage	4.5V-5.2V	4.8V-5.2V	4.8V-5.2V	4.8V-5.2V	4.8V-5.2V
Power	≤21W	≤14W	≤18W	≤16W	≤15W
Weight	338g	407g	408g	208g	130g
Frame frequency	60Hz
Refresh rate	≥1920Hz
Viewing angle	Horizontal 140°±10°,Vertical 140°±10°
Temperature	-10 to +60 deg C
Humidity	10% to 90%
Lifespan	≥100000 Hours
MTBF	≥10000 Hours
Malfunction Dot	less than 10 per million, in discrete state
