Features
1. Natural technique and classical design, dependable quality, and excellent performance.
2. Error <0.1 mm in screen flatness and seamless linking technology.
3. A patented mask that removes dark areas and enhances viewing angle and uniformity.
4. The best gray scale, with high contrast, presents the most realistic images.
5. Encouraging full-screen color and brightness correction.
6. The optimal power load and parameter settings enable the screen to function at its optimum, while also significantly reducing brightness and color degradation.
7.-High Precision Curved Lock
Rotational control, more accurate, easy to use and quickly adjust curve degree.
8.Support curved installation
Support mixed installation of 500*500mm(16.4ft*16.4ft) cabinets and 500*1000mm(3.28ft*16.4ft) cabinets.
Technical parameter
|
Model Number |
|||
|
Module Size |
250mm*250mm |
Pixel Pitch |
3.91 / 4.81 / 2.604 / 2.976mm |
|
Pixels Density |
65536Dots/m2 |
Pixel Resolution |
64*64=4096Dots |
|
Pixel Configuration |
1R1G1B |
Package Mode |
SMD 1921/2727 |
|
Drive Type |
Constant drive |
Scan Mode |
1/16 scan |
|
View Angle |
160°(W) 160°(H) |
Max Power |
36W |
|
Brightness |
≥800CD/m2 |
Weight |
0.55kg |
|
Electrical characteristics |
|||
|
Input current(constant) |
4.8-5.5V |
Maximum current |
4.5A |
|
Average Power Consumption |
100-300W/m2 |
Max Power Consumption |
≤800W/m2 |
|
Control Method |
Synchronization |
Driving Device |
Constant drive IC |
|
Refresh Frequency |
1920Hz |
Grey Scale/Colors |
4096gray level |
|
Pixel out of control |
<0.0002 |
Power Switch |
Automatic Switch |
|
Environmental |
|||
|
Usage |
Indoor/Outdoor |
Maintenance |
Front & Rear |
|
Working Temperature |
-20℃~50℃ |
Storage Temperature |
20℃~28℃ |
|
Relative Humidity |
10%-95% |
IP Rating |
IP65 |
|
Lifespan |
≥100000hours |
MTBF |
≥10000hours |
|
Warranty |
3 years |
Certications |
CE/ROHS/FCC /CCC |
