Features：
1. Fanless full screen design that uses little power and produces no noise.
2. High precision size: the unit boxes are nearly all the same size. Once assembled, the gaps are uniform, the screen is flat all around, and the effect looks fantastic.
3. Simple to maintain, simple to install, and simple to build and disassemble.
4. A high resolution may convey delicate colors and high definition visual quality, which is quite similar to LCD.
5. Both synchronous and asynchronous control cards are supported. It can still play and display normally even if the control computer malfunctions.
6. A variety of shapes, including square, arc, circle, rectangle, and other bespoke designs, can be created.
Technical Parameter
|
Model |
P1.2 |
P1.5 |
P1.6 |
P1.8 |
P2 |
P2.5 |
P3 |
P4 |
|
Pixel Pitch(mm) |
1.25 |
1.53 |
1.66 |
1.86 |
2 |
2.5 |
3 |
4 |
|
Pixel Matrix Per Sq.m |
422500 |
422500 |
360000 |
288906 |
250000 |
160000 |
90000 |
62500 |
|
Pixel Configuration |
SMD1212 |
SMD1212 |
SMD1212 |
SMD1515 |
SMD1515 |
SMD1515 |
SMD2121 |
SMD2121 |
|
Cabinet Resolution |
415x312 |
415x312 |
384x288 |
344x258 |
320x240 |
256x192 |
192x144 |
160x120 |
|
Power Con.(W/㎡) (Max / Avg) |
600W/200W |
600W/200W |
600W/200W |
580W/180W |
580W/180W |
550W/160W |
450W/160W |
450W/160W |
|
Refresh Rate (HZ) |
≥3840 |
≥3840 |
3840 |
3840 |
3840 |
≥1920 |
≥1920 |
≥1920 |
|
Brightness (cd/㎡) |
500-900 |
|||||||
|
Module Dimension |
320x160mm / 1.05x0.53ft |
|||||||
|
Cabinet Dimension |
640x480mm / 2.10x1.57ft |
|||||||
|
Cabinet Material |
Die Casting Aluminum |
|||||||
|
Cabinet Weight |
4.6KG |
|||||||
|
Service Access |
Front |
|||||||
|
Grey Scale (bit) |
14-22bit |
|||||||
|
Viewing Angle (H/V) |
160°/160° |
|||||||
|
IP Rate |
IP45 |
|||||||
|
Operation Temperature |
-20℃ ~ +80°℃ |
|||||||
|
Input Voltage (AC) |
110V / 220V |
|||||||
