Features
1. It can display incredibly clear and full images and movies with ultra-high definition and color reproduction, making it ideal for large-scale indoor and commercial displays.
2. Its high contrast and brightness allow it to sustain strong display effects in a range of lighting situations, giving viewers a more comfortable watching experience.
3. The P1.25 LED display also boasts a smoother, more natural display effect that gives viewers a sense of a more realistic picture scene. Its ultra-small pixel pitch and high refresh rate enable viewers to still distinguish text and images when up close. Its ultra-long life and low energy usage are further benefits, which might make using it more affordable and environmentally friendly for users.
Parameters
|
Item |
Parameter |
|
Model No. |
JL-PH1.25-64scan |
|
Led module size |
320x160MM |
|
Physical pitch |
1.25MM |
|
Physical Density |
640000 dot/m2 |
|
Package mode |
SMD 3IN1-1010 |
|
Module Resolution |
256dots(W)*128dots(H) |
|
Max Power |
22W |
|
Module thickness |
18mm |
|
Module Weight |
498g |
|
Drive type |
Constant drive |
|
Scan mode |
1/64scan |
|
Cabinet size |
640x480MM |
|
Cabinet size |
640x480MM |
|
best viewing angle |
H:140°;V:120° |
|
recommended viewing distance |
≥1.2m |
|
Driving IC |
ICN2163 |
|
Rate refresh |
3840Hz |
|
Brightness of white balance |
700cd/㎡ |
|
Input voltage |
110-220V;AC±10% |
|
operating temperature/humidity |
-20℃~+50℃ |
|
Average Power Consumption |
220w/㎡ |
|
Max. Power Consumption |
550w/㎡ |
|
MBTF |
>5000 hours |
Advantages of LED display
1. Restoration of natural color The color authenticity of the image can be entirely preserved, as can the color loss and deviation of the image produced by other display technologies, such as the display material, by utilizing the LED's light-emitting mechanism and point-by-point correction technology. It is possible to fully prevent backlight projection and light path while still achieving accurate color reproduction.
2. Exceptional brightness and cleverly adjusted Since the LED display itself has a relatively high brightness, it can be used with a light sensing system to automatically adjust the screen brightness to meet strong light and dark light environments, provide viewers with a more comfortable viewing experience, and prevent visual fatigue.
3. Quicker reaction time and high refresh rate As a widely utilized electronic display product, LED displays are not an exception. how many times the image on the screen is repeatedly scanned by the electron beam. The refresh rate increases with the number of scans, improving the steadiness of the displayed image. Comparably, we typically select a screen with a greater refresh rate when we play video games in order to feel our best; conversely, if the refresh rate is low, the image will jitter and flicker more severely, leading to faster eye fatigue.The shooting picture is stable, the image edge is clear, there is no ripple black screen, and the true information of the image itself is precisely recovered when the LED display is refreshed at a high rate.
4. Excellent color performance and high grayscale Compared to other display devices, which can display more picture details without losing information, the display can precisely depict grayscale even at low brightness, and the layering and vividness of the presented picture are significantly higher
5. Smooth cutting The effect of the border on the image quality cannot be avoided, despite the large number of LCD splicing displays available. LED displays can be spliced, but even ultra-narrow LCD screens cannot prevent cracks after splicing. Then, it will be possible to fully satisfy the requirements of seamless splicing.
6. The stereoscopic visual experience Customers that opt for a 3D display will be able to view incredible high-definition visuals, something that is not possible with traditional display devices. Consequently, it can provide you with the most vibrant and amazing visual experience, whether it's live TV, an exposition display, or digital advertising.
