Name: China Customized HD Small Pitch LED Display Manufacturers Suppliers Factory - ODM Service - Jiulong Optoelectronics
Brand: Jiulong
SKU: 228915841

Description

Technical Parameters

Features

1. The P1.5 display box is designed to be 16:9 for command and control and security monitoring screens, easily replacing 4:3 or 16:9 traditional display devices;

2. Die-cast aluminum box with high precision ensures the screen is smooth and seamless;

3. There are adjustment screws on the top, bottom, left and right inside the P1.5 LED display box, which can adjust the problem of bright and dark lines according to the situation; there is truly no bright and dark lines;

4. Magnetic module design, the module, system card and power supply all support front maintenance, and all cards and power supplies are double backed up;

5. The P1.5 full-color LED display screen has a uniform image and adopts non-linear point-by-point correction technology to make the image clearer and with a stronger sense of layering;

6. The P1.5 full-color display has a 140-degree viewing angle up, down, left, and right, broadcast-level color gamut, and intelligently adjustable color temperature and brightness, making it more suitable for long-term viewing;

7. Industry-leading 6H technology, achieving low brightness, high gray, high anti-static, and high refresh;

1001

Parameter

	Modle NO.	JL-PH1.538-52scan
	Module size	320mm*160mm
	Physical Density	422500 dot/m2
	Package mode	SMD 3IN1-1212
	Module Resolution	208dots(W)x104dots(H)
	Scan mode	1/52scan
	Module thickness	18mm

	Cabinet Size	640x480MM
	Cabinet resolution	416dot(W)x312dot(H)
	Rate refresh	3840Hz
	Brightness	700cd/㎡
	Input voltage	110-220V;AC±10%
	best viewing angle	H:140°;V:120°
	Operating temperature	-20℃~+50℃

	Pitch:P1.538
	Size:3.84x2.24M
	Resolution: 2496x1456px
	Address: United States
	Control system:Nova-star
	Video processor:VX600
	Module size:320x160MM

Installation method

1. Wall mounted installation

6001

2.Floor mounted installation

7001

3.Hanging installation

8001

4.Cantilever installation

9001

FAQ

Q: 1.What is indoor LED display?

A: Indoor led displays are large format screens that use LED technology. Unlike other technologies like LCD or OLED, they are seamless and can play any video format as well as still images, just like a large size PC monitor. They are made up of multiple cabinets.

Q: 2.How much is an indoor LED screen?

A: The cost of LED wall displays varies according to their size, style of installation, panel quality, and pixel size. An LED video panel typically costs between $600 and $3,000.

Q: 3.What is the difference between indoor and outdoor LED displays?

A: To survive wind, rain, dust, and other inclement weather, outdoor LED displays require a high degree of protection. Most outdoor LED displays are protected to IP65 or higher standards. Generally speaking, an IP20 or lower level of protection is sufficient for an interior LED display.

Jiulong Optoelectronics focuses on the research and exploration of LED large-screen display applications. We not only produce LED display large screens, but also provide you with professional-level display solution design and excellent display application technology services.
We maily produce fixed indoor and outdoor led display,rental led display,HD small pitch led display,led poster display,cob led display and so on.

10001
