Transparent LED Wall Rental

Transparent LED Wall Rental

Indoor transparent LED screens are mainly used in indoor installations, inside commercial windows, and inside low-rise glass curtain walls.
Send Inquiry
Description
Technical Parameters

1



Features



1.High permeability

The realization principle of transparent led wall rental is to optimize the light bar screen, improve the patch process, lamp beads, and add a hollow design structure to reduce the obstruction of the line of sight by structural components and improve the perspective effect. Can achieve 50%-75% permeability



2. Wide range of application scenarios

Transparent led wall rental are widely used in glass curtain walls, shopping malls, stores and other places. Because they can achieve video playback effects without affecting indoor lighting, they are loved by many friends.



3. High cost performance

With the maturity of LED screen manufacturers' manufacturing processes and the batch availability of materials, the cost of LED transparent screens has been well controlled. For example, the commonly used P3.9*7.8 model has a square unit price of no more than 2,000 yuan/square meter. Because of this factor, LED transparent screens are favored by more people.

2001



The advantages



1.Die-cast aluminum cabinet with a clear construction, weighing just 7.5 kg per piece,

2.2.70 percent transparency, much less wind resistance, improved cooling, and no interference with outside vision

3. A robust, stable screen body that effectively dissipates heat.
It is possible to mount or hang the screen on the window. interaction over multiple screens.

3.Installations that are fixed, suspended, and stacked are supported.

5. The viewing angle is broad, with up to 120° of vertical and horizontal viewing.
The greatest viewing area on a screen is provided by an ultra-wide viewing angle. It provides you with natural, crisp visuals in every direction.



Technical parameter





Item

Technical parameter














LED module

physical distance

3.91-7.81mm

product-378-104

pixel configuration

1R1G1B

Module size

500*125mm

LED encapsulation

SMD1921

pixel density(dot/㎡)

32768

pixel type

Full colour

Module pixels

128*16

Scan method

1/8scan

Drive IC

Constant current

Power supply voltage

5V

Operating Temp.

-30℃ - +50℃



















LED cabinet

Screen material

Profile aluminum

product-378-246product-377-242

Screen body color

Black / Silver / white

Cabinet size

1000*1000MM

Screen resolution

256*128

Transparency rate

65%

White balance brightness

5000cd/㎡

horizontal view angle

140egree

vertical viewing angle

140degree

planeness

<1mm

Module gap

<1mm

Cabinet weight

8KG

maximum power /㎡

1000W

Average power/㎡

500W

Frame rate

≥60Hz/s

refresh rate

1920/3840Hz

gray scale

16 bits

Input signal

RF,S-video,RGB,RGBHV,YUV,YC&Com

MTBF

>5000 hours

Life sapn

>100000 hours
