Technical parameters
|
Pixel Information |
2.604mm-outdoor |
2.976mm-outdoor |
3.91mm-outdoor |
|
LED Lamp |
SMD1415 |
SMD1415 |
SMD1921 |
|
Panel weight/kg |
0.58kg |
0.58kg |
0.65kg |
|
Cabinet size (mm) |
500*500/500*1000 |
500*500/500*1000 |
500*500/500*1000 |
|
Humidity |
10%-95%RH |
10%-95%RH |
10%-95%RH |
|
Quantity of panel |
16/8 |
16/8 |
16/8 |
|
Hub connecting |
HUB75 |
HUB75 |
HUB75 |
|
Controller |
Novastar Processor |
||
|
Best viewing angle |
Horizontal >170 Vertical>120 |
Horizontal >170 Vertical>120 |
Horizontal >170 Vertical>120 |
|
Best viewing distance |
3-30M |
3-30M |
3-30M |
|
Working temperature |
-20-60℃ |
-20-60℃ |
-20-60℃ |
|
Panel current |
8A |
8A |
8A |
|
Panel power supply |
5V |
5V |
5V |
|
Screen power supply |
220VAC/50HZ+_10% |
220VAC/50HZ+_10% |
220VAC/50HZ+_10% |
|
IP rating |
The back IP65,The front IP65 |
The back IP65,The front IP65 |
The back IP65,The front IP65 |
|
AC input Power Maximum Value(W/㎡) |
<800W/㎡ |
<800W/㎡ |
<800W/㎡ |
|
Average power |
350W |
300W |
250W |
|
Driving mode (scan) |
1/24Scanning |
1/21Scanning |
1/8Scanning |
|
Refresh frequency(Hz) |
1920-3840HZ |
1920-3840HZ |
1920-3840HZ |
|
Display color |
4096*4096*4096 |
4096*4096*4096 |
4096*4096*4096 |
|
Brightness(nit) |
4000cd/M2 |
5000cd/M2 |
4800cd/M2 |
|
Lifetime Typical Value(hrs) |
100000Hours |
100000Hours |
100000Hours |
|
Communication distance |
<100M |
<100M |
<100M |
Features
1. Lightweight and foldable The predominant material used in classic LED screen cabinets is SPCC (common & general use of cold-rolled carbon steel sheet and strip), also referred to as "iron box". Plates are joined together via bending, soldering, spraying, and other techniques. Its hefty weight is a drawback despite its cheap cost. After being turned into a screen, the weight per square meter exceeds 60 kg. Aluminum is the primary material utilized to construct cabinets for LED screen rentals in the theatrical performance sector. It has a weight of 30–50 kg/m^2. Among its qualities are its fine thermal conductivity and lightweight nature.
2.2. Minor alteration and smooth joining
Conventional LED screen cabinets use sheet metal as their manufacturing pattern, bending and welding the metal to make the cabinet. Screen deviation occurs at the millimeter level as a result of the wide variations in these production processes as well as the screens' frequent bending during processing.
Meeting smooth splicing standards is challenging. The variance may be kept to less than 0.1 millimeters thanks to the module forming equipment used in the production of aluminum cabinets for renting LED screens, fully satisfying the need of seamless splicing.
3. Installation that happens quickly
Because the cabinet is composed of aluminum, which is lighter and more precisely shaped, disassembly will be easy and quick. Within a few minutes, technicians can splice cabinets, significantly reducing installation and disassembly times and labor costs.
4. Trustworthiness
LED screens for outdoors are strong and long-lasting. It is resilient to inclement weather, including intense rain and wind. This means that, regardless of the weather, hiring a high-quality outdoor LED screen can provide crisp images and audio for the audience to enjoy. It is equipped with cutting-edge technologies and is weatherproof.
