Indoor Fine-Pitch Rental LED Display
P1.953/P2.604/P2.976/P3.91/P4.81 is very popular for events,with light weight,ultra-thing cabinet.
Features:
1.High Definition: LED display has excellent high resolution and high brightness, which can provide clear and vivid images and videos under various lighting conditions, making viewers feel as if they are in the real world
2 .Ultra-thin design: rental LED display usually adopts ultra-thin design, occupies less space, suitable for various occasions of building and leasing
3.Customizability: Rental LED display can be customized in size, shape and resolution to meet the requirements of different events and venues
4.Remote Control and Management: Remote control and management over the Internet for operator-friendly content updates and screen monitoring.
5.High reliability: Rental LED display usually have high reliability and stability, and can operate normally under adverse weather conditions.
6.Easy maintenance: modular design makes it relatively easy to maintain and replace damaged parts.
7.Standardized box structure: easy to dismantle, lightweight, easy to transport, adapted to large-area rental as well as fixed installation applications.
8.Versatility: Suitable for a variety of indoor and outdoor activities, it is a powerful tool for messaging and advertising.
9.Rich Video Playback Functions: Supports a variety of video formats, brightness, contrast, saturation, and chroma can be adjusted by software, with display synchronization function and image compression control .
10.Multiple display modes: with three display modes: overlapping, image and VGA, using the Line-Double function to convert interlaced frames to non-interlaced frames for motion compensation .
11.Audio signal support: provide one way audio signal to the amplifier to use, leave at least 2-way camera video input interface 4The LED display can be used in a wide variety of application scenarios.
12.These features make the stage Indoor Fine-Pitch Rental LED Display in a variety of application scenarios have a wide range of uses, such as large-scale performances , cultural evening , star singing will , sports events , concerts and performances , large-scale conferences and exhibitions
|
Model NO. |
P4.81 |
|
Pixel Pitch |
4.81mm |
|
LED type |
SMD1415 |
|
Flatness between modules |
≤ 0.1mm |
|
Pixel configuration |
1R1G1B |
|
Module size (W*H) |
250*250mm |
|
Module resolution (W*H) |
52*52mm |
|
Cabinet size(W*H*D) |
500*1000*75mm |
|
Cabinet resolution (W*H) |
104*208mm |
|
Cabinet weight |
14.5kg/pc |
|
Density |
43,264dots/m² |
|
IC |
2153 |
|
Scan |
32S |
|
Best viewing distance |
>2.6m |
|
Best viewing angle |
160°/ 120° |
|
Brightness |
5500-6000cd/m² |
|
Working voltage |
AC:110-240V 50~60Hz |
|
Maximum power |
≤600W/ m² |
|
Average power consumption |
200W/m² |
|
~300W / m² |
|
|
Screen temperature rise(running state) |
≤ 5 degrees |
|
Operation of Environmental Temperature/°C |
-10°C~60°C |
|
Operating Temperature |
10%~90%RH |
|
No condensation |
|
|
Screen color temperature |
2000K~9500K |
|
Driving method |
1/32 scanning |
|
Gray scale |
16 bits |
|
Refresh frequency |
≥3840Hz |
|
IP grade |
Front:IP68 |
|
Back:IP66 |
|
|
Continuous working time |
≥7×24hrs |
|
Lifetime |
100,000hrs |
|
Installation method |
Back Frame Installation / Hoisting / |
|
Pixel correction |
Equipped with point - by - point brightness and chromaticity correction |
|
Control mode |
Synchronization control |
|
Control distance |
Super five double stranded network cable, more than 100 meters using optical fiber transmission |
|
Software interface |
Windows XP /7/8/10 IOS |
|
Signal input |
HDMI,DVI, VGA, USB, LAN(Extensible interface) |
|
Cabinet material |
Waterproof Die-casting Aluminum |
|
Power Con |
Neut rick Power connector with cable |
|
Ether Con |
Neut rick Power connection with cable |
|
Maintenance method |
Dual Service, Front Maintenance and Back service |
|
Warranty time |
3 years warranty time and free lifetime technical support |
