Technical Parameters
|
Pixel Pitch(mm) |
1.25 |
1.53 |
1.667 |
1.86 |
2.0 |
2.5 |
|
Pixel Density(Dots/㎡) |
640,000 |
422,500 |
360,000 |
288,906 |
250,000 |
160,000 |
|
Module Size(mm) |
320(L) * 160(W) * 15(H) |
|||||
|
Module Weight(Kg) |
0.526 |
0.418 |
0.494 |
0.486 |
0.427 |
0.374 |
|
Module Input(V) |
4.2 ~ 5 |
|||||
|
Module Peak Power(W) |
≤ 25 |
|||||
|
Power Load Quantity(Pcs) |
6 |
|||||
|
Module Resolution(Dots) |
256 * 128 |
208 * 104 |
192 * 96 |
172 * 86 |
160 * 80 |
128 * 64 |
|
Cabinet Modules(Pcs) |
2x3 |
|||||
|
Cabinet Size(mm) |
640(L) * 480(W) * 65(H) |
|||||
|
Cabinet Weight(Kg) |
≤ 7.5 |
|||||
|
Cabinet Flatness(mm) |
＜ 0.1 |
|||||
|
Cabinet Area(㎡) |
0.3072 |
|||||
|
Cabinet Material |
Die casting aluminum |
|||||
|
Module Maintenance Mode |
All maintenance before |
|||||
|
White Balance Brightness(Nit) |
≥ 500(0~255 adjustable, adjustment step 1 |
|||||
|
Standard Color Temperature(K) |
6500(1000~9500 adjustable) |
|||||
|
Scanning Mode |
1 / 64 |
1 / 52 |
1 / 48 |
1 / 43 |
1 / 40 |
1 / 32 |
|
Working Voltage(V) |
110 ~ 240V 50 ~ 60Hz |
|||||
|
Working Temperature(℃)&. Humidity(RH) |
-10℃ ~ 50℃ &. 10% ~ 65% |
|||||
Features
1.Pixel Pitch (P1.86): Indicates the distance between individual pixels, with a lower value usually implying higher resolution.
2.High Resolution: Provides sharp and clear images, suitable for applications requiring detailed visuals.
3.LED Display Technology: Uses light-emitting diodes to produce bright and vibrant colors.
4.Slim Design: Thin profile for a sleek and modern look, making it suitable for various environments.
5.Wide Viewing Angle: Ensures clear visibility from different angles, making it suitable for large audiences.
6.Brightness: High brightness levels for better visibility in various lighting conditions, including well-lit environments.
7.Contrast Ratio: Offers a high contrast ratio for better differentiation between light and dark areas on the display.
8.Uniformity: Ensures consistent brightness and color across the entire video wall.
9.Seamless Integration: Ability to create large, seamless displays by combining multiple panels.
10.Energy Efficiency: Utilizes energy-efficient LED technology for reduced power consumption.
11.Advanced Calibration: Allows for precise color calibration and adjustment to achieve optimal image quality.
12.Durability: Designed for long-term use with robust construction and reliable components.
13.Remote Control and Management: Supports remote control and monitoring for easy operation and maintenance.
14.Customization: May offer customization options in terms of size, aspect ratio, and configuration.
15.Compatibility: Works well with various input sources, including computers, video players, and other multimedia devices.
