Features
1.Extremely small and light body: 40 mm in thickness and less than 35 kg in weight. Installed and moved by one person
2.Installation options include hanging, fold-out standing, foot mounting, and wall mounting, which can be implemented to satisfy various needs.
3.High definition visual experience high brightness (1000 nits), high refresh rate (3840 Hz), and pixel pitch of 2.5 mm. Excellent visual enjoyment is given to users by clear and vivid pictures.
4.Multiple control options: USB stick, Lan cable, HDMl, or WIFl are available to users. It is accessible for monitoring on PC, iPad, iPhone, and Android devices.There are numerous forms available, including picture, music, video, flash, clock, countdown, and weather forecasting.
5.For malls and shopping centers, digital poster led display produces high-quality campaign images and videos. Excellent for branding and enhancing the shopping experience for consumers.
Technical parameter
|
Spec |
Pitch 2.5mm |
|
Module Size |
320mm x 160mm |
|
Module Size in Inches |
12,6in x 6,3in |
|
Panel Resolution(dots) |
128 x 64 |
|
Screen Size |
640*1920*50mm |
|
Panel Weight |
41 kgs |
|
Driver IC |
MBI/ICN |
|
Color Grayscale (Bit) |
16 Bit |
|
LED Configuration |
SMD1515 |
|
Viewing Angle Degree |
160°/160° |
|
Brightness(Nits) |
1200 |
|
Scanning |
1/32 |
|
Transmission Distance |
CAT5/130m/426ft |
|
AC Input Frequency(Hz) |
60 |
|
Refresh Rate(Hz) |
3840 |
|
IP Rate |
IP33 |
|
Max Power per Panel |
720W |
|
Average Power per Panel |
220W |
|
Lifetime Value |
100000 Hours |
|
Operating Temperature |
-40°C~+60°C |
|
Operating Humidity |
10~90%RH |
|
Communications |
WiFi/Lan/USB |
|
Maintenance |
Front&Back |
